Bush Reducing MXF 40mmx15mm

Home/Store Catalogue/Galvanised Malleable Fittings/Bush Reducing MXF

SKU 66-CT-4015GRB

Request a quote

Quantity:

Product Details

Brand: ARKAM PLUMBING

Weight: 0.20 kg

Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.

Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron

Dimensions Table

ITEM CODE BSP METRIC mm A

66-CT-2015GRB 3/4" x 1/2" 20mm x 15mm 24mm

66-CT-2515GRB
1" x 1/2" 25mm x 15mm 28mm

66-CT-2520GRB 1" x 3/4" 25mm x 20mm 28mm

66-CT-3215GRB 1 1/4" x 1/2" 32mm x 15mm 30mm

66-CT-3220GRB 1 1/4" x 3/4" 32mm x 20mm 30mm

66-CT-3225GRB 1 1/4" x 1" 32mm x 25mm 30mm

66-CT-4015GRB 1 1/2" x 1/2" 40mm x 15mm 30mm

66-CT-4020GRB 1 1/2" x 3/4" 40mm x 20mm 30mm

66-CT-4025GRB 1 1/2" x 1" 40mm x 25mm 30mm

66-CT-4032GRB 1 1/2" x 1 1/4" 40mm x 32mm 30mm

66-CT-5015GRB 2" x 1/2" 50mm x 15mm 33mm

66-CT-5020GRB 2" x 3/4" 50mm x 20mm 33mm

66-CT-5025GRB 2" x 1" 50mm x 25mm 33mm

66-CT-5032GRB 2 x 1 1/4" 50mm x 32mm 33mm

66-CT-5040GRB 2" x 1 1/2" 50mm x 40mm 33mm

ITEM CODE	BSP	METRIC mm	A

66-CT-2015GRB	3/4" x 1/2"	20mm x 15mm	24mm
66-CT-2515GRB	1" x 1/2"	25mm x 15mm	28mm
66-CT-2520GRB	1" x 3/4"	25mm x 20mm	28mm
66-CT-3215GRB	1 1/4" x 1/2"	32mm x 15mm	30mm
66-CT-3220GRB	1 1/4" x 3/4"	32mm x 20mm	30mm
66-CT-3225GRB	1 1/4" x 1"	32mm x 25mm	30mm
66-CT-4015GRB	1 1/2" x 1/2"	40mm x 15mm	30mm
66-CT-4020GRB	1 1/2" x 3/4"	40mm x 20mm	30mm
66-CT-4025GRB	1 1/2" x 1"	40mm x 25mm	30mm
66-CT-4032GRB	1 1/2" x 1 1/4"	40mm x 32mm	30mm
66-CT-5015GRB	2" x 1/2"	50mm x 15mm	33mm
66-CT-5020GRB	2" x 3/4"	50mm x 20mm	33mm
66-CT-5025GRB	2" x 1"	50mm x 25mm	33mm
66-CT-5032GRB	2 x 1 1/4"	50mm x 32mm	33mm
66-CT-5040GRB	2" x 1 1/2"	50mm x 40mm	33mm
