Caps Round 20mm

Home/Store Catalogue/Galvanised Malleable Fittings/Caps Round

SKU 66-CT-20GC

Request a quote

Quantity:

Product Details

Brand: ARKAM PLUMBING

Weight: 0.07 kg

Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.

Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron

Dimensions Table

Item Code BSP METRIC mm A

66-CT-15GC
⅜” 15mm

66-CT-20GC
3/4" 20mm 22mm

66-CT-25GC
1" 25mm 24mm

66-CT-32GC
1 1/4" 32mm 27mm

66-CT-40GC
1 1/2" 40mm 28mm

66-CT-50GC
2" 50mm 32mm

66-CT-80GC
3"
80mm
39mm

Item Code	BSP	METRIC mm	A
66-CT-15GC	⅜”	15mm
66-CT-20GC	3/4"	20mm	22mm
66-CT-25GC	1"	25mm	24mm
66-CT-32GC	1 1/4"	32mm	27mm
66-CT-40GC	1 1/2"	40mm	28mm
66-CT-50GC	2"	50mm	32mm
66-CT-80GC	3"	80mm	39mm
