GALVANISED ELBOW 90° MXF 15mm
SKU 66-CT-15GMFE
Request a quote
1
Product Details
Brand: ARKAM PLUMBING
Weight: 0.10 kg
Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.
Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron
Dimensions Table
| ITEM CODE | BSP | METRIC mm | A | B |
|---|---|---|---|---|
|
66-CT-15GMFE |
½” | 15 | 28 | 38 |
|
66-CT-20GMFE |
¾” | 20 | 33 | 44 |
Save this product for later
GALVANISED ELBOW 90° MXF 15mm
