GALVANISED ELBOW 90° REDUCING 20mmx15mm

Home/Store Catalogue/Galvanised Malleable Fittings/Elbows 90°/Elbow 90° Reducing

SKU 66-CT-2015GRE

Request a quote

Quantity:

Product Details

Brand: ARKAM PLUMBING

Weight: 0.10 kg

Features:

Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.

Technical Data:

Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron

Dimensions Table

Item Code	BSP	METRIC mm	A	B
66-CT-2015GRE	3/4" x 1/2"	20mm x 15mm	30mm	31mm
66-CT-2520GRE	1" x 3/4"	25mm x 20mm	35mm	36mm
