GALVANISED EQUAL TEE 20mm
SKU 66-CT-20GT
Request a quote
1
Product Details
Brand: ARKAM PLUMBING
Weight: 0.16 kg
Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.
Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron
Dimensions Table
| Item Code | BSP | METRIC mm | A |
|---|---|---|---|
|
66-CT-15GT |
1/2" | 15mm
|
27mm |
|
66-CT-15GT |
3/4" | 20mm | 32mm |
|
66-CT-25GT |
1"
|
25mm
|
37mm
|
|
66-CT-32GT |
1 1/4"
|
32mm
|
44.5mm
|
|
66-CT-40GT |
1 1/2"
|
40mm
|
49mm
|
|
66-CT-50GT |
2" | 50mm
|
57mm |
