GALVANISED NIPPLE BARREL 40mm
SKU 66-CT-40GBN
Request a quote
1
Product Details
Brand: ARKAM PLUMBING
Weight: 0.20 kg
Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.
Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron
Dimensions Table
| Item Code | Size | Metric Conversion | C |
|---|---|---|---|
|
66-CT-15GBN |
1/2" | 15mm | 50mm |
|
66-CT-20GBN |
3/4" | 20mm | 53mm |
|
66-CT-25GBN |
1" | 25mm | 60mm |
|
66-CT-32GBN |
1 1/4" | 32mm | 75mm |
|
66-CT-40GBN |
1 1/2" | 40mm | 78mm |
|
66-CT-50GBN |
2" | 50mm | 85mm |
|
66-CT-80GBN |
3" | 80mm | 100mm |
