GALVANISED PLUGS HOLLOW 40mm

Home/Store Catalogue/Galvanised Malleable Fittings/Plugs Hollow

SKU 66-CT-40GP

Request a quote

Quantity:

Product Details

Brand: ARKAM PLUMBING

Weight: 0.14 kg

Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.

Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron

Dimensions Table

Item Code Size Metric Conversion A

66-CT-15GP 1/2" 15mm 21mm

66-CT-20GP
3/4" 20mm 23mm

66-CT-25GP
1" 25mm 26mm

66-CT-32GP
1 1/4" 32mm 30mm

66-CT-40GP
1 1/2" 40mm 31mm

66-CT-50GP
2" 50mm 36mm

66-CT-80GP
3" 80mm 48mm

Item Code	Size	Metric Conversion	A

66-CT-15GP	1/2"	15mm	21mm
66-CT-20GP	3/4"	20mm	23mm
66-CT-25GP	1"	25mm	26mm
66-CT-32GP	1 1/4"	32mm	30mm
66-CT-40GP	1 1/2"	40mm	31mm
66-CT-50GP	2"	50mm	36mm
66-CT-80GP	3"	80mm	48mm
