GALVANISED SOCKET 80mm
SKU 66-CT-80GS
Request a quote
1
Product Details
Brand: ARKAM PLUMBING
Weight: 0.82 kg
Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.
Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron
Dimensions Table
| Item Code | BSP | METRIC mm | A |
|---|---|---|---|
|
66-CT-15GS |
1/2" | 15mm | 35mm |
|
66-CT-20GS |
3/4" |
20mm |
38mm |
|
66-CT-25GS |
1" |
25mm |
44mm |
|
66-CT-32GS |
1 1/4" |
32mm |
49mm |
|
66-CT-40GS |
1 1/3" |
40mm |
53mm |
|
66-CT-50GS |
2" |
50mm |
63mm |
|
66-CT-80GS |
3" |
80mm |
74mm |
