GALVANISED SOCKET REDUCING 20mmx15mm

Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.

Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron

---

Item Code	BSP	Metric Conversion	A
66-CT-2015GRS	3/4" x 1/2"	20mm x 15mm	38mm
66-CT-2515GRS	1" x 1/2"	25mm x 15mm	44mm
66-CT-2520GRS	1" x 3/4"	25mm x 20mm	44mm
66-CT-3215GRS	1 1/4" x 1/2"	32mm x 15mm	49mm
66-CT-3220GRS	1 1/4" x 3/4"	32mm x 20mm	49mm
66-CT-5040GRS	2" x 1 1/2"	50mm x 40mm	63mm
