GALVANISED UNION CONICAL 25mm

Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.

Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron

Dimensions Table

Item Code	Size	Metric Conversion	A
66-CT-15GU	1/2"	15mm	46mm
66-CT-20GU	3/4"	20mm	50mm
66-CT-25GU	1"	25mm	56mm
66-CT-32GU	1 1/4"	32mm	63mm
66-CT-40GU	1 1/2"	40mm	68mm
66-CT-50GU	2"	50mm	76mm
