GALVANISED ELBOW 90° 15mm
SKU 66-CT-15GE
Request a quote
1
Product Details
Brand: ARKAM PLUMBING
Weight: 0.07 kg
Features:
Hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.
Technical Data:
Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron
Dimensions Table
| Item Code | BSP | Metric Conversion | A |
|---|---|---|---|
|
66-CT-15GE |
1/2" | 15mm | 27mm |
|
66-CT-20GE |
3/4" | 20mm | 32mm |
|
66-CT-25GE |
1" | 25mm | 37mm |
|
66-CT-32GE |
1 1/4" | 32mm | 44.5mm |
|
66-CT-40GE |
1 1/2" | 40mm | 49mm |
|
66-CT-50GE |
2" | 50mm | 57mm |
|
66-CT-80GE |
3" | 80mm | 77.5mm |
